Technical Specifications
Product Code: SY-BR-AUT-UWC
• Maximum Current Rating: 400A Continuous (600A Peak Rating for Heavy-Duty Thermal Cutting)
• Operating Voltage: Up to 120V DC (Standard Underwater Cutting & Welding Rating)
• Switch Mechanism: Heavy-Duty Double-Pole Safety Isolator Knife Switch
• Cable Termination Ports: High-Flex Cam-Lock / DINSE Style Heavy-Gauge Output Leads & Connectors
• Enclosure Protection: IP66 / NEMA 4X Weatherproof Marine Enclosure with Dual Twist-Locks
• Enclosure Mounting: Heavy-Duty Webbed Retention Strap with Quick-Release Tension Buckle
• Overall Dimensions (L x W x H): Approx. 1500 mm x 800 mm x 1400 mm
• Tare Weight (Dry): Approx. 120 kg – 150 kg (Frame + Switch Enclosure)
• Frame Material: Heavy-Duty Tubular Structural Steel (316 Stainless Steel Option Available)
• Deck Base Surface: Heavy-Duty Steel Mesh Grating for Fluid Drainage and Non-Slip Traction
• Protective Coating: Marine-Grade Epoxy Primer with High-Visibility Polyurethane Safety Orange Finish
• Lifting & Handling: Four-Point Top Pad Eyes for Crane Rigging; Integrated Base Forklift Pockets
