Technical Specifications
Product Code: SY-CBA
• Charging Rate: 87 CFM (2464 L/min) @ 175 psi (12 bar)
• Engine: 230 / 415 / 460 V / E3 / 50 or 60 Hz
• Engine Power: 25 hp (18.6 kW)
• Max Operating Pressure: 200 psi (14 bar)
• RPM: 951
• Number of Stages: 2
• Lubrication: Pressure
• Air Quality: Grade D Breathing Air
• Volume Tank (Gas Receiver) ASME rated: 1 x 120 Gallons (545 ltr)
• Filtration System: Hankison 3 stage
• Diver manifold: 4
• Dimensions: 3 x 34 x 63 in
• (L x W x H): (185 x 86 x 160 cm)
• Weight: 2060 lb (934 kg)
