The Stanley IW24 is an extreme heavy-duty 1-1/2" square drive hydraulic impact wrench designed for demanding underwater bolting applications, including underwater nut and bolt running, anchor bolt driving and other heavy-duty underwater tasks. As the largest model in the Stanley underwater impact wrench range, the IW24 features a rugged swing-hammer impact mechanism with adjustable impact intensity from 1088 to 4760 Nm and forward and reverse rotation. The large D-style handle and feathering trigger provide the commercial diver with excellent control and ease of handling, while the swing-hammer mechanism helps reduce torque transmission to the diver and makes servicing easier. The Stanley IW24 is supplied without couplings; couplings and hose whips can be supplied separately.
Technical Specifications
Product Code: SY-IW24
• Weight: 19.5 kg
• Brand: Stanley
• Power Type: Hydraulic
• Capacity: 1088–4760 Nm
• Fitting: 1-1/2" Square Drive
• Hydraulic Flow: 26–45 lpm
• Pressure: 124–140 bar
• Couplings: No
• Port Size: -8 SAE O-Ring
• Stainless steel spools and fasteners
• D-style handle
• Adjustable impact intensity
• Forward and reverse with variable speed
• Cast-in lifting eye
