Technical Specifications
Product Code: SY-BC-4P-M
• Series: PX0941 – 900 Series Buccaneer
• Connector Type: Circular Socket (Female), Flange Panel Mount
• Number of Contacts: 7
• Contact Gender: Socket (Female)
• Contact Material: Nickel-Plated Brass
• Body Material: Polyamide (UL94V-0 rated)
• Insulator Material: High-Density Thermoplastic
• Termination Type: Axial Screw
• Voltage Rating: Up to 450 V
• Current Rating: Dependent on application (see datasheet)
• Operating Temperature: -40°C to +85°C
• Ingress Protection: IP68 / IP69K (when properly mated and sealed)
• Flammability Rating: UL94V-0
• Certifications: UL, CSA, VDE
• Mounting Thread: M6 (recommended for panel fixing)
