The Fibron Mini TV Cable DCS0005 is designed for reliable video transmission in surface-supplied diving and bell operations. Engineered for harsh marine environments, it ensures stable signal performance while offering excellent resistance to abrasion, kinking, and mechanical stress.
Technical Specifications
Product Code: SY-FIBRON-DCS0005
Applications:
Used within bell excursions and surface dive umbilicals for video and monitoring.
Construction & Features:
• Multi-core configuration: Designed for integrated video and signal transmission
• Outer Sheath: Orange polyurethane, approx. 1.4 mm thickness for enhanced protection
• High durability: Resistance to abrasion, marine conditions, and handling stress
• Flexible design: Suitable for both static and dynamic applications
Specifications:
• Standard Continuous Length: 500 m (1,650 ft)
• Outside Diameter: 11 mm
• Weight in Air: 165 kg/km
• Weight in Sea Water: 72 kg/km
• Density: 1,788 kg/km
• Minimum Bend Radius (Static): 70 mm
• Minimum Bend Radius (Dynamic): 105 mm
• Minimum Break Strength: N/A
• Standard Color: Orange
